Factory supplier 43 lnch kiosk display with IR touch
1,Adopt hardened metal shell,antistatic,preventing magnetic strong interference.
2, With 3mm thickness tempered glass as protection layer against the surface of LCD screen.
3,Safely locking system function to avoid flash memory card and advertising playing contents being taken away, also can be protected by password.
4, With content USB update feature
5,Playlists support functions,
2, With 3mm thickness tempered glass as protection layer against the surface of LCD screen.
3,Safely locking system function to avoid flash memory card and advertising playing contents being taken away, also can be protected by password.
4, With content USB update feature
5,Playlists support functions,
| Panel Details | |
| Screen size | 43lnch |
| Resolution | 1920 (RGB) x 1080 (FHD) |
| Display size | 941.184 x 529.416 mm (H x V) |
| Visual size | 945.18 533.42mm (H V) |
| Brightness (CD /m2) | 400 (Typ.) |
| Best Angle | full Angle |
| Visual Angle | 178/178(Min.)(CR 10) |
| Constract | 1400:1 |
| Point distance | 0.227mm (H) x 0.227mm (W) |
| Quantity of colors | 16.7m /1.07B, 95% [CIE1931] |
| Refresh frequency | 60Hz |
| Signal system | LVDS (2 ch, 10-bit), terminals, 51 pins |
| Supply voltage | 12.0V (Typ.) |
| storage temperature | - 20 ~ 60 ° C temperature: 0 ~ 50 ° C |
| Screen type | LCD module, a-Si TFT-LCD. |
| Pixel configuration | RGB vertical bar |
| Appearance size | 975.5 582.2 10.5(H V D) |
| Surface preparation | Haze (3%), Hard coating (1H) |
| Optical mode | IPS, often black display, transmission type |
| Response speed | 6 (Typ.)(G to G) ms |
| Backlight type | WLED, 30K hours, no drive |
| Andriod Configurantion | |
| CPU | Quad-core/Octa-core |
| RAM | 1G/2G/4G optional |
| ROM(Internet Memory) | 8G/16G/32G optional |
| OS | Andriod 4.4/5.1/6.0/7.1 optional |
| PC Configurantion | |
| CPU | I3/I5/I7 Intel 1037U optional |
| RAM | 4G/8G optional |
| Hard Disk | 500GB HDD or 64/120/240GB SSD |
| OS | Window 7/10 optional |
